Rolls Royce Merlin Parts Catalog 1950 | Online Manuals

ROLLS ROYCE MERLIN PARTS CATALOG has 610, pages 2nd Issue, May 1950 Contents Page No. Air Compressor Fittings 176 Controls 178 Ignition Wire Fittings 185 Fuel Pump 193 Supercharger 199 Operating Mechanism (2-s peed Supercharger) 213 Fuel Pipe 221 Supercharger Drive 222 Air Pipes 234 Intercooler 236 Automatic Boost Control 243 Air Compressor Drive (Heywood) 253 Constant Speed and Vacuum Pump Drive 254 Micellaneous Installation Fittings 259 Special Repair Parts 260A Carburettor- Bendix 8D 44/1 261 Magneto Rotax C7, 8 and 9 296 Magneto Bt-H, C6 315 Electric Starter Motor F.E.4 328 Numerical Parts List 330 Numerical Reference Number List 377.
