Piper Saratoga II HP/II TC Parts Catalog PA-32R-301 & 301T Part # 761-880_v2006 | Online Manuals

Piper PA-32R-301 Saratoga II HP (SERIAL NUMBERS 3246001 AND UP) PA-32R-301T Saratoga II TC (SERIAL NUMBERS 3257001 AND UP) Piper Parts Catalog/ Piper Parts Manual Part Number 761-880 (ORG950712) dated 1996 with revision to September 10, 2006. The manual is 456 pages long. MODEL SERIAL NUMBER INFORMATION: The serial numbers of PA-32R-301 Saratoga II HP aircraft covered by this Parts Catalog are as follows: MODEL YEAR 1995 3246001 thru 3246017 MODEL YEAR 1996 3246018 thru 3246059 MODEL YEAR 1997 3246060 thru 3246087 MODEL YEAR 1998 3246088 thru 3246125 MODEL YEAR 1999 3246126 thru 3246153 MODEL YEAR 2000 3246154 thru 3246165 MODEL YEAR 2000 3246166 thru 3246181 MODEL YEAR 2001 3246182 thru 3246203 MODEL YEAR 2002 3246204 thru 3246209 MODEL YEAR 2003 3246210 thru 3246217 MODEL YEAR 2004 3246218 thru 3246226 MODEL YEAR 2005 3246227 and up The serial numbers of PA-32R-301T Saratoga II TC aircraft covered by this Parts Catalog are as follows: MODEL YEAR 1997 3257001 thru 3257027 MODEL YEAR 1998 3257028 thru 3257075 MODEL YEAR 1999 3257076 thru 3257123 MODEL YEAR 2000 3257124 thru 3257143 MODEL YEAR 2000 3257145 thru 3257155 MODEL YEAR 2000.5 3257144 thru 3257144 MODEL YEAR 2000.5 3257156 thru 3257198 MODEL YEAR 2001 3257199 thru 3257266 MODEL YEAR 2002 3257267 thru 3257296 MODEL YEAR 2003 3257297 thru 3257338 MODEL YEAR 2004 3257339 thru 3257369 MODEL YEAR 2005 3257370 and up TABLE OF CONTENTS: SECTION I- WING GROUP SECTION II- FUSELAGE GROUP SECTION III- TAIL SURFACES GROUP SECTION IV- LANDING GEAR GROUP SECTION V- CABIN EQUIPMENT GROUP SECTION VI- INSTRUMENTS GROUP SECTION VII- POWER PLANT GROUP SECTION VIII- FUEL SYSTEM GROUP SECTION IX- CONTROL SYSTEM GROUP SECTION X- HYDRAULIC SYSTEM GROUP SECTION XI- ENVIROMENTAL GROUP SECTION XII- ELECTRICAL SYSTEM SECTION XIII- ELECTRONICS SYSTEM SECTION XIV- MISCELLANEOUS GROUP NUMERICAL INDEX.
