PIPER CHEROKEE PARTS CATALOG PART NUMBER # 753-582 Parts Manual for the PA-28-140 PA-28-180 PA-28-150 PA-28-235 PA 28-160 PA-28R-180 PA-28R-200 has 827 pages ISSUED: AUGUST 16, 1973 REVISED: JUNE 10, 2009 PA-28 AND PA-28R SERIAL NUMBER INFORMATION The following information should be kept in mind when ordering from this catalog: a. The serial numbers of the aircraft covered by this Part Catalog are as follows: (1) Serial numbers of the 1961 PA-28-150 and PA-28-160 Models are 28-1 to 28-84 inclusive. (2) Serial numbers of the 1962 PA-28-150 and PA-28-160 Models are 28-85 to 28-670 inclusive. (3) Serial numbers of the 1963 PA-28-150 and PA-28-160 Cherokee “B” Models are 28-725 to 28-1760 inclusive. (4) Serial numbers of the PA-28-180 Cherokee “B” Models are 28-671 to 28-1760 inclusive. (5) Serial numbers of the PA-28-150, PA-28-160 and PA-28-180 Cherokee “C” Models are 28-1761 to 28-4377 inclusive. (6) Serial numbers of the PA-28-180 Cherokee “D” Models are 284378 to 28-5600 inclusive. (7) Serial numbers of the PA-28-180 Cherokee “E” Model- are 28-5601 to 28-5869 inclusive. (8) Serial numbers of the PA-28-180 Cherokee “F” Models are 28-7105001 to 28-7105244 inclusive. (9) Serial numbers of the PA-28-180 Cherokee “G” Models are 28-7205001 to 28-7205328 inclusive. (10) Serial numbers of the 1973 PA-28-180 Cherokee Models are 28-7305001 to 28-7305611 inclusive, and 28-E13. (SEE NOTE) (11) Serial numbers of the 1974 PA-28-180 Cherokee Models are 28-7405001 to 28-7405290 inclusive. (12) Serial numbers of the 1975 PA-28-180 Cherokee Models are 28-7505001 to 28-7505261 inclusive. (13) Serial numbers of the PA-28-140 Models are 28-20002 to 28-24999 inclusive. (14) Serial numbers of the PA-28-140 Cherokee “B” Models are 28-25000 to 28-26400 inclusive. (15) Serial numbers of the PA-28-140 Cherokee “C” Models are 28-26401 to 28-26956 inclusive. (16) Serial numbers of the PA-28-140 Cherokee “D” Models are 28-7125001 to 28-7125651 inclusive. (17) Serial numbers of the PA-28-140 Cherokee “E” Models are 28-7225001 to 28-7225612 inclusive. (18) Serial numbers of the 1973 PA-28-140 Cherokee Models are 28-7325001 to 28-7325684 inclusive. (19) Serial numbers of the 1974 PA-28-140 Cherokee Model are 28-7425001 to 28-7425454 inclusive. (20) Serial numbers of the 1975 PA-28-140 Cherokee Models are 28-7525001 to 28-7525350 inclusive (21) Serial number of the 1976 PA-28-140 Cherokee Models are 28-7625001 to 28-7625234 inclusive. (22) Serial numbers of the 1977 PA-28-140 Cherokee Models are 28-7725001 to 28-7725290 inclusive, (23) Serial numbers of the PA-28-235 Models are 28-10003 to 28-10719 inclusive, (24) Serial numbers of the PA-2B-235 Cherokee “B” Models are 28-10720 to 28-11039 inclusive. (25) Serial numbers of the PA-28-235 Cherokee “C” Model are 28-11040 to 28-11300 inclusive. (26) Serial numbers of the PA-28-235 Cherokee “D” Models are 28-11301 to 28-11393 inclusive. (27) Serial numbers of the PA-28-235 Cherokee “E” Models are 28-7110001 to 28-7110042 inclusive. (28) Serial numbers of the PA-28-235 Cherokee “F” Models are 28-7210001 to 28-7210033 inclusive. (29) Serial numbers of the 1973 PA-28-235 Cherokee Models are 28-7310001 to 28-7310187 inclusive, and 28-E11. (SEE NOTE) (30) Serial numbers of the 1974 PA-28-235 Cherokee Models are 28-7410001 to 28-7410120 inclusive. (31) Serial numbers of the 1975 PA-28-235 Cherokee Models are 28-7510001 to 28-7510145 inclusive. (32) Serial numbers of the 1976 PA-28-235 Cherokee Models are 28-7610001 to 28-7610206 inclusive. (33) Serial numbers of the 1977 PA-28-235 Cherokee Models are 28-7710001 to 28-7710089 inclusive. NOTE: PA-28-180 with serial number 28-E13 and PA-28-235 with serial number 28-E11 are not referenced in the various Parts Lists throughout this catalog. PA-28-180 with serial number 28-E13 is to be serviced the same as serial number 28-7305001. PA-28-235 with serial number 28-E11 is to be serviced the same as serial number 28-7310001.
