Piper Archer II & III Parts Catalog PA-28-181 Part # 761-678_v1994 | Online Manuals

Piper Archer II & II PA-28-181 Piper Parts Catalog/ Piper Parts Manual Part Number 761-678 dated 1978 with revision to (CR940915) September 15, 1994. The manual is 444 pages long. MODEL SERIAL NUMBER INFORMATION; The serial numbers of the aircraft covered by this Parts Catalog are as follows: Serial Numbers of the 1976 PA-28-181 ARCHER II Models are 28-7690001 thru 28-7690467. Serial Numbers of the 1977 PA-28-181 ARCHER II Models are 28-7790001 thru 28-7790607. Serial Numbers of the 1978 PA-28-181 ARCHER II Models are 28-7890001 thru 28-7890551. Serial Numbers of the 1979 PA-28-181 ARCHER II Models are 28-7990001 thru 28-7990589. Serial Numbers of the 1980 PA-28-181 ARCHER II Models are 28-8090001 thru 28-8090372. Serial Numbers of the 1981 PA-28-181 ARCHER II Models are 28-8190001 thru 28-8190318. Serial Numbers of the 1982 PA-28-181 ARCHER II Models are 28-8290001 thru 28-8290178. Serial Numbers of the 1983 PA-28-181 ARCHER II Models are 28-8390001 thru 28-8390090. Serial Numbers of the 1984 PA-28-181 ARCHER II Models are 28-8490001 thru 28-8490112. Serial Numbers of the 1985 PA-28-181 ARCHER II Models are 28-8590001 thru 28-8590092. Serial Numbers of the 1986 PA-28-181 ARCHER II Models are 28-8690001 thru 28-8690008, 28-8690010 thru 28-8690011, 28-8690014 thru 28-8690017, 28-8690019 thru 28-8690056, 2890001 thru 2890008, 2890010 thru 2890021, 2890023 thru 2890025. Serial Numbers of the 1987 PA-28-181 ARCHER II Models are 28-8690009, 28-8690012, 28-8690013, 28-8690018, 2890009, 2890022, 2890026 thru 2890048. Serial Numbers of the 1988 PA-28-181 ARCHER II Models are 2890049 thru 2890099. Serial Numbers of the 1989 PA-28-181 ARCHER II Models are 2890100 thru 2890136, 2890140 thru 2890145, 2890147, 2890149 thru 2890153. Serial Numbers of the 1990 PA-28-181 ARCHER II Models are 2890137 thru 2890139, 2890146, 2890148, 2890154, 2890168 thru 2890169. Serial Numbers of the 1992 PA-28-181 ARCHER II Models are 2890155 thru 2890167, 2890170. Serial Numbers of the 1993 PA-28-181 ARCHER II Models are 2890171 thru 2890195. Serial Numbers of the 1994 PA-28-181 ARCHER II Models are 2890196 thru 2890205. Serial Numbers of the 1994 PA-28-181 ARCHER III Models are 2890206 and up. TABLE OF CONTENTS: SECTION I- WING GROUP SECTION II- FUSELAGE GROUP SECTION III- TAIL SURFACES GROUP SECTION IV- LANDING GEAR GROUP SECTION V- CABIN EQUIPMENT GROUP SECTION VI- INSTRUMENTS GROUP SECTION VII- POWER PLANT GROUP SECTION VIII- FUEL SYSTEM GROUP SECTION IX- CONTROL SYSTEM GROUP SECTION X- ENVIRONMENTAL GROUP SECTION XI- ELECTRICAL SYSTEM GROUP SECTION XII- ELECTRONICS GROUP SECTION XIII- MISCELLANEOUS GROUP NUMERICAL INDEX.
