Piper Apache PA-23-150 & PA-23-160 Service Manual Part # 752-422 | Online Manuals

Piper Apache PA-23-150 PA-23-160 Piper Service Manual/ Piper Maintece Instructionns Manual Part Number 752-422 (ORG) dated 1950 with revision to October 5, 1999. The manual is 454 pages long. EFFECTIVITY This service manual is effective for all PA-23-150 and PA-23-160 airplanes as follows: Model Name Model Number Serial Numbers Model Years Apache PA-23-150 23-1 thru 23-1182 1954 - 1958 PA-23-160 23-1183 thru 1870 1958 - 1959 Apache G PA-23-160 23-1871 thru 23-2012 23-2044 thru 23-2046 1960 - 1962 Apache H PA-23-160 23-2013 thru 23-2043 1962 SECTION INDEX GUIDE; I- INTRODUCTION II- HANDLING AND SERVICING III- INSPECTION IV- STRUCTURES V- SURFACE CONTROLS VI- HYDRAULIC SYSTEM VII- LANDING GEAR AND BRAKE SYSTEM VIII- POWER PLANT IX- FUEL SYSTEM X- INSTRUMENTS XI- ELECTRICAL SYSTEM XII- ELECTRONICS XIII- HEATING AND VENTILATING.
