Installation Manual for the J.P. Instruments FS-450 Fuel Flow has 9 pages Cover date August 16, 2000 Table of Contents; 1. General 2. External annunciator light 3. Install the instrument in the panel 4. Route the Fuel Flow Transducer Wires 5. Installing the Fuel Flow Transducer 6. Specifications and Limitations Drawing 450124 mounting template Drawing 450507 wiring diagram Initial Check Out System Checkout Operating Instructions Instructions for Continued Airworthiness Appendix –A Report No. 503, transducer installation.
