J.P Instruments EGT-701 with Fuel Flow Installation Manual 1997 | Online Manuals

Installation Manual for the J.P Instruments EGT-701 with Fuel Flow Option has 14 pages Cover date: March 14, 1997 Table of Contents: 1. General 2. Initial Check Out 3. Installing the Fuel Flow Transducer 4. Route the Optional warning control line 5. Install the instrument in the panel 6. Route the Fuel Flow Transducer Wires 7. System Checkout 8. Specifications and Limitations 9. Pilot Programmable Modes 10. Drawing 700923 11. Drawing 700922 12. Drawing 700921 13. Drawing 700124 (excerpt from report #103, STC 2586NM) 14. Drawing 700744 (excerpt from report 103, STC 2586NM) 15. Drawing 700920 Installing the Fuel Flow Differential Module FFDM-1 or FFDM-2.
