Insight Strike Finder Installation Manual | Online Manuals

Installation Manual for the Insight Strike Finder has 20 pages Document No: 2000-10, Rev. 1.7.1 March 2, 2001 contents: Installation 2.1 Unpacking the Strike Finder 2.2 Selecting the Strike Sensor Mounting Location 2.3 Mounting the Strike Sensor 2.4 Wiring 2.5 Selecting a Heading Source 2.6 Checking the Installation 2.7 TSO Limitations 2.8 Final Acceptance Testing 2.9 Using Dealer Mode 2.10 Ground and Flight Testing 2.11 Troubleshooting 2.12 Weight & Balance Data Environmental Qualification Form Display (Part No. 2000-021) Sensor (Part No. 2000-022) Drawings Sensor Mounting Ass’y (DWG. No. 2000-004) Interconnect Diagram (DWG. No. 2000-019) Sensor Outline (DWG. No. 2000-029) Display Outline (DWG. No. 2000-030) Sensor Mounting Detail (DWG. No. 2000-035) 4 – Hole Sensor Mounting Detail (DWG. No. 2000-036) Display Mounting Detail (DWG. No. 2000-040).
