Garmin G3X Installation Manual 190-01115-01 | Online Manuals

Installation Manual for Garmin G3X has 498 pages long 190-01115-01 Rev. K: July 2013 Table of Contents Section 1 Inventory of Materials Section 2 Installation Preparation Section 3 GAD 29 Installation (Optional LRU) Section 4 GAP 26 Installation (Optional LRU) Section 5 GDU 37X Installation (Core G3X LRU) Section 6 GEA 24 Installation (Optional LRU) Section 7 GMC 305 Installation (Optional LRU) Section 8 GMU 22 Installation (Core G3X LRU) Section 9 GSA 28 Installation/Configuration (Optional LRU) Section 10 GSU 25 Installation (Core G3X LRU) Section 11 GSU 73 Installation (Core G3X LRU) Section 12 GTP 59 Installation (CORE G3X LRU) Section 13 GPS/XM Antenna Installation (Core G3X LRU) Section 14 Engine/Airframe Sensor Installation (Optional) Section 15 LRU Pinouts Section 16 Connector Installation Instructions Section 17 Configuration, Software, Databases, and XM Activation Section 18 Engine/Airframe Sensor Configuration Section 19 Post-Installation Checkout and Calibration Procedures Section 20 Troubleshooting Section 21 Return to Service Information Appendix A Airframe Specific Installation Guidance Appendix B Outline & Installation Drawings Appendix C G3X w/GSU 25 and/or GAD 29 Interconnect Drawings Appendix D G3X w/GSU 73 Interconnect Drawings Appendix E Sensor Wiring Examples Appendix F Lycoming/Continental Sensor Wiring Examples Appendix G Rotax Sensor Wiring Examples Appendix H Jabiru Sensor Wiring Examples Appendix I RS-232 Text Output Format.
